The Manual/Electric Actuator is used to manually or
electrically release nitrogen gas pressure from a
Nitrogen Cylinder to pneumatically activate a control
head through a Pneumatic Actuation Network. The
body of the Manual Actuator is chrome plated brass
and contains a stainless steel puncture point and
upper shaft. This upper shaft contains a palm button,
locked in place by a stainless steel ring pin, and also
accepts a Linear Actuator (P/N 22579 or 20500). A
1/4” NPT female port is used to connect to the
Pneumatic Actuation Network. The Manual/Electric
Actuator is supplied with two 1/4”-20 stainless steel
cap screws (P/N 10573-P012) for securing the
assembly to an Actuator Bracket.
